Front Entrance Doors

FLUSH HARDWOOD DOORS AND HARDWOOD DOORS WITH PLANT ON MOULDING

  • frontprod01
    MIL 1
  • frontprod01
    MIL 2
  • frontprod01
    MIL 3
  • frontprod01
    MIL 4
  • frontprod01
    MIL 5
  • frontprod01
    MIL 6
  • frontprod01
    MIL 7
  • frontprod01
    MIL 8
  • frontprod01
    MIL 9
  • frontprod01
    MIL 10
  • frontprod01
    MIL 11
  • frontprod01
    MIL 12
  • frontprod01
    MIL 13
  • frontprod01
    MIL 14
  • frontprod01
    MIL 15
  • frontprod01
    MIL 16
  • frontprod01
    MIL 17
  • frontprod01
    MIL 18
  • frontprod01
    MIL 19
  • frontprod01
    MIL 20

  • Features

  • Specifications

  • PDF Downloads

Features

  • feat-laminate-iconTri-laminate Anti-Vandal door blank
  • feat-sbd-icon-newSecured by Design Certification. Door set meets PAS 24 :2016
  • feat-fd-iconAll doorsets are FD30 (30 minute fire integrity)
  • feat-liping-iconHardwood lipped
  • feat-icon1Traditionally manufactured for maximum strength and durability
  • feat-partm-iconComplies with Part M regulations for wheelchair access
  • feat-weather-iconWeather proofed and draught proofed
  • feat-custom-iconCustom designs on request

Specifications

Sizes:
  • Bespoke doors made to suit most openings
Ironmongery:
  • 3 point multi locking (Mul-T-Lock ML240 or ML235) with euro profile cylinder and internal thumbturn operation (to facilitate emergency exit in case of fire) or, provide key operation both sides if so instructed by client
  • 5 no. Mul-T-Lock keys and 1 no. Keycard
  • 8mm continuous zintec hinge onto new hardwood frame
  • OR
  • 3-no. adjustable hinge block on frame armour cladding with hinge bolts, onto existing hardwood or softwood frame
  • Pull handle
Alternative Frames:
  • Steel frame armour profiles (Fit onto existing timber frame)
  • 70x95mm rebated hardwood frame
  • 80x40x2mm stainless steel hollow section
Hardware:
  • Surface mounted door closer
  • Door numeral
  • Letter plate with internal security cowl
  • Wide-angle viewer
  • Security chain
  • Perimeter draught seal
  • Intumescent with smoke seal
Options:
  • Solid hardwood cill
  • Low level threshold strip for wheelchair/disability access
  • External weatherboard (if required)
  • Fanlights and sidelights
Finishes:
  • Teknos painted or stained

PDF Downloads
