Features

  • 44mm / 54mm thick tri-laminate Anti-Vandal door blank
  • Full length gap guard protection to lock
  • This traditional style door and screen sets are available in conventional mortise and tenon construction or in a unique 'one piece' design where the glazed apertures are routed into solid core panels with raised muntins applied to each side.
  • Complies with Part M regulations for wheelchair access
  • Custom designs on request

Specifications

Sizes:
  • Bespoke doors made to suite most opening
Ironmongery
  • 12mm stainless steel continuous hinge onto hardwood frame or stainless steel frame
  • Stainless steel pull handle 225x22mm or stainless steel long pull handle
  • Stainless steel push plate
Alternative Frames:
  • 80x40x2mm stainless steel hollow section
  • 100x50x2mm stainless steel hollow section
  • 70x95mm rebated hardwood frame
Alternative Glazing:
  • Pyroshield georgian wire glass
  • Laminated glass
  • Obscure glass
  • Double glazed sealed unit
  • FD 30 and FD 60 Glazing
Hardware:
  • Surface mounted door closer
  • Stainless steel full height gap guard
  • Stainless steel full width gap guard on top
  • Stainless steel kick plate internal and external
Options:
  • Magnalock housing to be manufactured from 60x40x2mm (for M32 magnets) or 100x50x2mm (for M82 magnets)
  • stainless steel hollow section fixed with security screws
  • Mul-T-Lock, ASSA lock with electric strike
  • Upgrade from surface mounted door closer to an LCN2035 concealed door closer
  • RX100 low level threshold (if required)
  • Fanlights and sidelights
Finishes:
  • Sikkens painted or stained

PDF Downloads

Please Note

All/any electrical equipment to be disconnected and connected by others. Electrical equipment supply and connected by others.
